item no.:
PEEK CFPayment:
Discussedproduct origin:
ChinaColor:
Natural color or Customizedshipping port:
XiamenLead Time：
2-10 workings days
Long Carbon Fiber Reinforced PEEK (Polyether Ether Ketone) is an ultra-high-performance thermoplastic composite designed for extreme engineering environments. Reinforced with 40% long carbon fiber, PEEK-LCF40 delivers outstanding mechanical strength, wear resistance, chemical stability, and continuous high-temperature performance. It is widely used in aerospace, automotive, energy, and high-end industrial applications where metal replacement and long-term reliability are required.
PEEK-LCF40 consists of a polyether ether ketone matrix reinforced with 40% long carbon fibers. The long fiber network significantly enhances load transfer efficiency, resulting in superior stiffness, fatigue resistance, creep resistance, and dimensional stability compared with short carbon fiber PEEK materials.
| Property | Unit | Typical Value |
|---|---|---|
| Tensile Strength | MPa | 259 |
| Tensile Modulus | MPa | 39730 |
| Flexural Strength | MPa | 314 |
| Flexural Modulus | MPa | 26415 |
| Notched Izod Impact | kJ/m² | 22 |
| Heat Deflection Temperature (1.8 MPa) | °C | 315 |
| Density | g/cm³ | 1.45 |
PEEK-LCF40 is an ultra-high-performance composite material made by reinforcing PEEK with 40% long carbon fiber, offering extreme strength, heat resistance, and durability.
It provides exceptional mechanical performance, outstanding heat resistance, excellent wear resistance, chemical stability, and long-term reliability under extreme conditions.
It is widely used in aerospace, automotive, oil & gas, semiconductor equipment, industrial machinery, and high-end engineering applications.
Long carbon fibers significantly improve load-bearing capacity, fatigue resistance, dimensional stability, and structural performance compared to short fiber composites.
Yes. It is widely used as a metal replacement material in extreme environments requiring high strength, wear resistance, and thermal stability.
Contact our engineering team for material selection guidance, processing recommendations, datasheets, and customized ultra-performance PEEK carbon fiber solutions.
